GYFXJBY
Single-Core Flat Cable is composed of a 2.0mm single-core cable and two parallel non-metallic strength members, then extruded with an LSZH (Low Smoke Zero Halogen) outer jacket.
Specification
Outstanding crush resistance
The single-core sub-cable features flame retardancy
Aramid reinforcement plus dual parallel strength members secure reliable tensile strength
Compact diameter, lightweight and easy for installation
Suitable for duct laying, aerial installation and building drop cabling
| Fiber Count | Outer Diameter (mm) |
Nominal Weight (kg/km) |
Allowable Tensile Load (N) IEC 60794-1-21-E1 |
Crush Resistance (N/100MM) IEC 60794-1-21-E3 |
Min. Bend Radius (mm) |
|||
| Long-term | Short-term | Long-term | Short-term | Dynamic | Static | |||
| 1F | 4(±0.2)×7.0(±0.3) | 45 | 300 | 600 | 500 | 1000 | 20D | 10D |
| Operating Temperature Range (℃): -20~+60 | ||||||||
